RealSense learning/turtorial/sharing blog - Chapter Four: Frame Issues
What is the next step after getting the frames?
while examining the collected data, there are some issues needed to be fixed, and this post will focus on this part
The visualization will use openCV and the example file will be:
poll_for_frames()
|
Will send back None value is the image is not matched
adding:
if not depth_frame or not color_frame:
continue
will prevent error while running
|
wait_for_frames()
|
it will automatically pair frames with order, not timestamp or index
So when I record the file with long gap in time, the paring is not correct |
try_wait_for_frames
|
it can set one time limit for wait_for_frames
|
So, now is the main issue I mention for this chapter
the wait for frames will pair each as the color shown
It will match first 243 / 274, then 243 / 301, 270 / 301, 302 / 306, 302 / 333, and so on
So when I have one frame gap with few seconds, the content of Color and Depth will be very different if I use wait_for_frames
timestamp
|
Frame number
|
Fream number
|
timestamp
|
402204.595
|
Depth243
|
Color 274
|
402204.221
|
403104.714
|
Depth 270
|
Color 301
|
403104.941
|
404171.521
|
Depth 302
|
Color306
|
403271.741
|
406038.434
|
Depth359
|
Color333
|
404172.461
|
407305.267
|
Depth 397
|
Color 389
|
406040.621
|
407338.605
|
Depth398
|
Color 427
|
407308.301
|
408038.697
|
Depth419
|
Color 449
|
408042.221
|
409238.855
|
Depth 455
|
Color 485
|
409243.181
|
409938.947
|
Depth476
|
Color 506
|
409943.741
|
410705.715
|
Depth 499
|
Color 529
|
410711.021
|
How did I try to fix it?
I recorded the frame number, and match wait_for_frame with it,
that means, first I wait for Depth frame number 243, if the Color frame number is 274, it shows
if not, it will search until it founds it (so sometimes when the frame is drop, it will stuck)
This takes a bit longer to run when the bag file is big, but at least accurate.
After the first one, it will search for Depth 270 and Color 301
as automatically it will get 243 / 301 next, I take the 301 and then wait for frame and get 270, skip one frame
but when it happens at 302/301, I want to get 302/306, but it will straight go to 359 /306, I have to make the whole file run to the end, and start from the beginning again.
This takes some time if the file is big, not so satisfying but its working for now.
